- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Packaged Quantity
- 1 Pack
- Product Type
- Device Server
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- Connectivity Technology
- Wired
- Data Link Protocols
- TCP
- UDP
- IP Rating
- IP30
- Media & Performance
- Media Type Supported
- Twisted Pair
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Network Standard
- 10/100/1000Base-T
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Serial Port
- Yes
- Total Number of Network Ports
- 2
- Number of Network (RJ-45) Ports
- 2
- Number of Serial Ports
- 16
- Environmental Conditions
- Minimum Operating Temperature
- 14°F (-10°C)
- Maximum Operating Temperature
- 140°F (60°C)
- Power Description
- Input Voltage
- 12 V DC
- 48 V DC
- Power Consumption
- 5.60 W
- Physical Characteristics
- Form Factor
- Rack-mountable
- Height
- 1.7"
- Width
- 17.2"
- Depth
- 10.2"
- Weight (Approximate)
- 6.83 lb
- Miscellaneous
- Certifications & Standards
- CE
- EN 55011
- EN 55032 Class A
- EN 61000-6-4
- FCC Part 15 Subpart B Class A
- EN 61000-4-2 (Level 4)
- EN 61000-4-3 (Level 3)
- EN 61000-4-4 (Level 4)
- EN 61000-4-5 (Level 4)
- EN 61000-4-6 (Level 3)
- EN 61000-4-8 (Level 4)
- EN55024
- IEC 60068-2-32
- UL 60950-1
- UL 62368
- IEC 60068-2-6
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
