Measuring less than 3.5 inches deep and 2 inches wide, the IE-MiniMc Series converters are some of the industry's smallest copper-to-fiber media converters, with both data connections on the same side. The IE-MiniMc family of media converters are a fraction of the cost of other industrial grade alternatives. These products provide the ease and convenience of plug-and-play operation with features including Auto Negotiation and Auto-Cross.
Multiple powering options include Power over Ethernet (PoE/PD), AC wall adapter and USB, which offers unsurpassed flexibility for a variety of installations.
- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- B+B SmartWorx
- Product Line
- IE-MiniMc
- Product Type
- Transceiver/Media Converter
- Interfaces/Ports
- Total Number of Ports
- 2
- Network (RJ-45)
- Yes
- DVI
- No
- USB
- No
- Parallel Port
- No
- Digital Audio
- No
- Digital Audio/Video
- No
- Management Port
- No
- Number of Network (RJ-45) Ports
- 1
- Number of ST Ports
- 1
- Media & Performance
- Media Type Supported
- Optical Fiber
- Twisted Pair
- Fiber Mode Supported
- Multi-mode
- Maximum Distance Supported
- 5 km
- Fiber Optic Cable Core/Cladding Specification
- 9/125 µm
- 50/125 µm
- 62.5/125 µm
- Network & Communication
- Ethernet Technology
- Fast Ethernet
- Network Technology
- 100Base-FX
- 10/100Base-TX
- Physical Characteristics
- Form Factor
- Desktop
- Rail-mountable
- Wall Mountable
- Height
- 0.8"
- Width
- 1.8"
- Depth
- 3.4"
- Miscellaneous
- Certifications & Standards
- FCC Class A
- FCC Class B
- UL/cUL
- CSA
- CE
- 802.3
- 802.3u
- 802.3af
