TITANONE
Digital Signage All-in-One Management System
Universal mounting solution for displays and Digital Engine series, which are protected inside a locked embedded compartment. Cable management solution also included.
ENGINECORE
4U Rack for Six Digital Engines
Consolidate six Digital Engines with the Engine Core - an innovative practical solution for networked environments. Enhance security, monitoring and protection from data loss via a hardware-centric approach.
Also provides a green IT, easy-maintenance solution for cluster (parallel) computing.
- General Information
- Manufacturer
- AOpen, Inc
- Manufacturer Website Address
- http://www.aopen.com
- Brand Name
- AOpen
- Product Line
- Digital Engine
- Product Type
- Digital Signage Appliance
- Warranty
- Limited Warranty
- 1 Year
- Technical Information
- Features
- Shock Absorbent
- Cable Management
- Media Player
- Processor & Chipset
- Processor Model
- T56N
- Processor Speed
- 1.60 GHz
- Processor Core
- Dual-core (2 Core)
- Memory
- Standard Memory
- 4 GB
- Maximum Memory Supported
- 8 GB
- Memory Technology
- DDR3 SDRAM
- Storage
- Total Hard Drive Capacity
- 320 GB
- Hard Drive Interface
- Serial ATA
- Network & Communication
- Ethernet
- Yes
- Ethernet Technology
- Gigabit Ethernet
- I/O Expansions
- Number of Internal 2.5" Bays
- 1
- Expansion Slot Type
- Mini PCI Express
- Total Number of Expansion Slots
- 1
- Interfaces/Ports
- USB
- Yes
- USB Standard
- USB 2.0
- USB 3.0
- DVI
- Yes
- VGA
- Yes
- DisplayPort
- Yes
- Network (RJ-45)
- Yes
- Audio Line Out
- Yes
- Serial
- Yes
- Software
- Operating System
- Windows Embedded Standard 7
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Power Consumption
- 65 W
- Physical Characteristics
- Height
- 1.9"
- Width
- 6.5"
- Depth
- 6.2"
- Weight (Approximate)
- 2.43 lb
- Miscellaneous
- Certifications & Standards
- FCC
- CE
- cULus
- CB
- BSMI
- Environmentally Friendly
- Yes
- Energy Efficiency Compliance
- Energy-related Products Directive (ErP)
