Unique and Independent | Functional Operations
- Fast processing and print speeds up to 6ips - Built-in 5 Mega Pixel camera to quickly scan barcodes
- Compatible with BPL-Z™, BPL-E™ as well as SLCS™, BXL/POS
- BIXOLON's Food Safety Label, Label Artist Mobile and mPrint App are supported on the BIXOLON Downloader.
- Diverse SDKs supported for building customer applications
- Optional BIXOLON's web-based printer profile management (XCM™)
Seamless Connectivity
- USB and Ethernet connection between tablet and printer for fast and accurate data transmission
- 2 USB Host Ports + Ethernet + WLAN + Bluetooth interface supported for Tablet
- BIXOLON Pass Through App - Directly sending printing data to XQ-840 by multiple host device with WLAN
Ergonomic Design
- Anti-theft, water and dust resistant design
- 8-inch Android Tablet with multi-touch screen
- Field installable Peeler and Auto Cutter
- Adjustable Media Holders and Guides
- General Information
- Manufacturer
- Bixolon America, Inc
- Manufacturer Website Address
- http://www.bixolon.com
- Brand Name
- Bixolon
- Product Type
- Direct Thermal Printer
- Technical Information
- Recommended Use
- Label Print
- Print Color Capability
- Monochrome
- Maximum Mono Print Speed
- 5.98 in/s
- Maximum Print Resolution (dpi)
- 203
- Maximum Print Length
- 39.37"
- Maximum Print Width
- 4.25"
- Barcode Symbology Supported
- 1D
- 2D
- Codabar
- Code 11
- Code 39
- Code 93
- Code 128
- EAN-13
- EAN-8
- Industrial 2 of 5
- Interleaved 2 of 5
- LOGMARS
- MSI
- Plessey
- POSTNET
- GS1 DataBar (RSS-14)
- Standard 2 of 5
- IMB
- UPC-A
- UPC-E
- UPC-EAN Extensions
- AZTEC
- Maxi Code
- Micro PDF-417
- TLC 39
- QR Code
- PDF417
- Real Time Clock
- Yes
- Application/Usage
- Restaurant
- Retail
- Healthcare
- Manufacturing
- Features
- Water Resistant
- Dust Resistant
- Ergonomic
- Connectivity Technology
- Wired & Wireless
- Fonts Included
- Bitmap Fonts
- SLCS
- BPL-Z
- BPL-E
- Scalable Font
- Unicode supported
- UTF-16BE
- UTF-8
- UTF-16LE
- Print Technology
- Direct Thermal
- Memory
- Standard Memory
- 64 MB
- Flash Memory
- 128 MB
- Interfaces/Ports
- USB Host
- Yes
- USB
- Yes
- Network & Communication
- Ethernet
- Yes
- Ethernet Technology
- Ethernet
- Bluetooth
- Yes
- Bluetooth Version
- 4.2
- Wireless LAN
- Yes
- Wireless LAN Standard
- IEEE 802.11a/b/g/n/ac
- Display & Graphics
- Display Screen
- Yes
- Screen Size
- 8"
- Display Screen Type
- LCD
- Media Types & Handling
- Media Type
- Reflective
- Label
- Black Mark
- Gap
- Notch
- Continuous Label
- Fanfold
- Wristband
- Tag
- Receipt
- Media Sensor
- Head Open Sensor
- Transmissive Media Sensor
- Reflective Media Sensor
- Adjustable Media Sensor
- Media Thickness
- 7.87 mil
- Maximum Roll Diameter
- 5.12"
- Maximum Label Width
- 4.65"
- Fonts & Emulation
- Language Emulation
- BXL/POS
- SLCS
- BPL-Z
- ZPL II
- BPL-E
- EPL
- Power Description
- Power Source
- AC Supply
- Power Adapter
- Frequency
- 60 Hz
- 50 Hz
- Environmental Conditions
- Operating Temperature
- 32°F (0°C) - 104°F (40°C)
- Operating Relative Humidity
- 80%
- Storage Temperature
- -4°F (-20°C) - 140°F (60°C)
- Storage Relative Humidity
- 10% - 90%
- Physical Characteristics
- Form Factor
- Wall Mount
- Color Family
- Black
- Product Color
- Black
- Height
- 8.3"
- Width
- 7.6"
- Depth
- 10.7"
- Weight (Approximate)
- 4.85 lb
- Miscellaneous
- Package Contents
- Android Tablet Embedded 4 inch Direct Thermal Label Printer
- Micro USB (5P)
- Platform Supported
- Android
- Energy Star
- Yes
