The CyberPower PDU15SW8FNET, an 8-outlet (front), 1U rackmount switched power distribution unit (PDU), provides 120V 15A output. It distributes power to 8 NEMA 5-15R receptacles from a single NEMA 5-15P plug with unfiltered electrical pass-through. The switched outlet receptacles can be managed individually or collectively over the network, using the CyberPower Management Console, a web browser, and the RJ45 Ethernet port for network connection, or locally by using the LCD controls.
- General Information
- Manufacturer
- CyberPower Systems, Inc
- Manufacturer Website Address
- https://www.cyberpowersystems.com/
- Brand Name
- CyberPower
- Product Type
- PDU
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- PDU Type
- Switched
- Plug/Connector Type
- NEMA 5-15P
- Receptacle Type
- NEMA 5-15R
- Receptacle Detail
- 8 x NEMA 5-15R
- Locking Receptacles
- Cord Retention Tray
- Features
- LCD Display
- Power Description
- Input Voltage
- 120 V AC
- Output Voltage
- 120 V AC
- Output Voltage Range
- 100 V AC - 120 V AC
- Input Current
- 15 A
- Input Frequency
- 60 Hz
- Management
- Management
- SNMP
- HTTP
- TCP/IP
- UDP
- DHCP
- SNMP
- HTTP
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Mount Type
- Rack-mountable
- Rack Height
- 1U
- Cord Length
- 12 ft
- Height
- 1.8"
- Width
- 17.1"
- Depth
- 4.4"
- Weight (Approximate)
- 5.29 lb
- Environmental Conditions
- Minimum Operating Temperature
- 32°F (0°C)
- Maximum Operating Temperature
- 113°F (45°C)
- Minimum Storage Temperature
- 5°F (-15°C)
- Maximum Storage Temperature
- 113°F (45°C)
- Miscellaneous
- Package Contents
- PDU15SW8FNET
- Mounting Brackets (2 Sets)
- Cord Retention Tray
- Cord Organizers
- User Manual
- Certifications & Standards
- UL60950-1 Certified by ETL (USA)
- CSA C22.2(Canada)
- FCC Class A
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
