FULL HD IPS DISPLAY
Designed for professionals, this Full HD display with IPS technology minimizes color shifts and provides outstanding picture quality from virtually any viewing angle.
PERSONALIZED VIEWING ANGLES AND EASY ASSEMBLY
The 24BK550Y-H provides comfortable viewing with versatile screen height/tilt/pivot/swivel adjustments. You can customize the display condition to create a more personal, comfortable workstation.
Easy Assembly and Wall Mounting Capability
The 24BK550Y-H can be assembled quickly and easily, without the need for any tools. Also, the wall mounting design gives you the freedom to take it off the desk and hang it on a wall.
INTEGRATED POWER MODULE FOR ORGANIZED WORKSPACES
The power module is integrated with the monitor, helping to reduce the amount of power modules in your workspace.
Mini PC Connection Available
The 24BK550Y-H is designed for the discreet mounting of compatible mini PCs on the rear. A mini PC can be easily mounted behind the monitor stand with an LG bracket. Height cannot be adjusted when mini PC weight exceeds 300g (stand lowered due to heavy weight). LG bracket (or retaining clip) and mini PC sold separately.
- General Information
- Manufacturer
- LG Electronics
- Manufacturer Website Address
- https://solutions.lg.com/us
- Brand Name
- LG
- Product Type
- LCD Monitor
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Number of Screens
- 1
- Screen Size Class
- 24"
- Viewable Screen Size
- 23.8"
- Screen Mode
- Full HD
- Screen Surface
- Anti-glare
- Panel Technology
- In-plane Switching (IPS) Technology
- Response Time
- 5 ms
- Response Time Details
- 5 ms GTG
- Aspect Ratio
- 16:9
- Pixel Pitch
- 0.27450 mm x 0.27450 mm
- Horizontal Viewing Angle
- 178°
- Vertical Viewing Angle
- 178°
- Mount Type
- Wall Mountable
- Maximum Adjustable Height
- 5.12"
- Tilt Angle
- -5° to 35°
- Features
- Display Data Channel/Command Interface (DDC/CI)
- Key Lock
- Super Resolution+
- 6-axis Color Adjustment
- Color Calibration
- Variable Picture Mode
- Smart Energy Saving
- Flicker-free
- Reading Mode
- Plug & Play
- Dual Controller
- Off Timer
- Intelligent Auto
- OnScreen Control
- Horizontal Frequency
- 30 kHz to 83 kHz - HDMI
- 30 kHz to 83 kHz - DVI-D
- 30 kHz to 83 kHz - DisplayPort
- Vertical Frequency
- 56 Hz to 75 Hz - VGA
- 56 Hz to 75 Hz - DVI-D
- 56 Hz to 75 Hz - HDMI
- 56 Hz to 75 Hz - DisplayPort
- 50 Hz to 61 Hz - HDMI
- Stand Adjustments
- Swivel
- Height
- Tilt
- Pivot
- Pivot
- Yes
- Curved Screen
- No
- Glass Hardness
- 3H
- Video
- Maximum Resolution
- 1920 x 1080
- Maximum Resolution (DisplayPort)
- 1920x1080
- Maximum Resolution (HDMI)
- 1920x1080
- Color Supported
- 16.7 Million Colors
- Contrast Ratio
- 1,000:1
- Dynamic Contrast Ratio
- 5,000,000:1
- Brightness
- 250 Nit
- Color Gamut
- 72% DCI-P3 (CIE 1976)
- Native Resolution
- 1920 x 1080
- Maximum Resolution (DVI-D)
- 1920 x 1080
- Audio
- Number of Speakers
- 2
- Speakers
- Yes
- Speaker Output Power
- 1.20 W
- Interfaces/Ports
- Network (RJ-45)
- No
- HDMI
- Yes
- HDMI Version
- 1.4
- USB
- Yes
- VGA
- Yes
- Headphone
- Yes
- DisplayPort
- No
- DisplayPort Version
- 1.2
- Thunderbolt
- No
- Number of HDMI Inputs
- 1
- Number of USB 2.0 Upstream Ports
- 1
- Number of USB 2.0 Downstream Ports
- 2
- Number of DisplayPorts
- 1
- Number of VGA Ports
- 1
- Audio Line In
- Yes
- DisplayPort Input
- Yes
- DisplayPort Output
- No
- Number of Audio Line Out Ports
- 1
- Built-in Devices
- Built-in Devices
- Speaker
- Webcam
- No
- Software
- Operating System Supported
- Windows 10
- Power Description
- Input Voltage Range
- 120V to 230V
- Operating Power Consumption
- 23.60 W
- Standby Power Consumption
- 500 mW
- Off-Mode Power Consumption
- 300 mW
- Frequency
- 50 Hz
- 60 Hz
- Physical Characteristics
- VESA Mount Compatible
- Yes
- VESA Mount Standard
- 100 x 100
- Color Family
- White
- Product Color
- Textured White
- Stand Color
- White Textured
- Height
- 15.1"
- Width
- 21.8"
- Depth
- 9.4"
- Weight (Approximate)
- 12.61 lb
- Weight with Stand (Approximate)
- 7.94 lb
- Height with Stand Down
- 2.76"
- Miscellaneous
- Additional Information
- HDR Effect:No
- HW Calibration:No
- LED Color (Power save mode).1
- Key Type.1
- Key Location.1
- LED Color (On Mode).2
- Picture-by-Picture (PBP):No
- Picture-in-Picture (PIP):No
- TAA Compliance:No
- Wide Color Gamut (WCG):No
- Local Dimming Zone:No
- HDR 10:No
- Surface Treatment (Haze):No
- Nano IPS™ Technology:No
- Contrast Ratio with DFC:No
- VESA DisplayHDR:No
- Curvature:No
- Color Weakness:No
- Black Equalizer:No
- DAS Mode:No
- MBR (Supported Frequencies):No
- Auto Input Switch:No
- User Define Key:No
- Borderless Design:No
- Output Frequency:No
- MaxxAudio®:No
- Output dB:No
- Local Key Operation:Yes (Menu, OK / Input, Power)
- Microphone In (3.5 mm):No
- Thunderbolt™ (V Frequency):No
- Thunderbolt™ (USB-Compatibility):No
- RS-232C In (3.5 mm 4-pin):No
- Thunderbolt™ (Max Resolution):No
- Built-in Mic:No
- RADEON FreeSync™:No
- Motion Blur Reduction Technology:No
- OverClocking:No
- Black Stabilizer®:No
- Crosshair:No
- FreeSync™ (Low Frame Compensation):No
- FPS Counter:No
- Dynamic Action Sync®:No
- AMD FreeSync™:No
- Auto Brightness Sensor:No
- Local Dimming:No
- Low Blue Light:No
- Color Blind Mode:No
- LG Callibration Studio:No
- Thunderbolt Certification:No
- USB-IF:No
- CEC (Regulatory):No
- TUV Eyesafe:No
- TUV LBL:No
- USB-C (VESA):No
- ERP (Environmental):No
- TUV-TYPE (Regulatory):No
- Energy Star (Environmental):No
- IEC (Electrical):No
- USB Type-C In:No
- Port Location
- PVC-Free
- Certifications & Standards
- CE (Regulatory)
- UL Listed
- Yes
- Environmentally Friendly
- Yes
- Environmental Certification
- Electronic Product Environmental Assessment Tool Bronze (EPEAT Bronze)
- TÜV Geprüfte Sicherheit
- TÜV Geprüfte Sicherheit
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Country of Assembly
- China
