- General Information
- Manufacturer
- LG Electronics
- Manufacturer Website Address
- https://solutions.lg.com/us
- Brand Name
- LG
- Product Line
- Pro Centric
- Product Series
- LN570H
- Product Type
- LED-LCD TV
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Screen Size Class
- 32"
- Viewable Screen Size
- 32"
- Backlight Technology
- LED
- Operating System
- WebOS 22
- Features
- Instant On
- Remote Jack Pack (RJP)
- Welcome Screen
- Pro:Centric Direct
- Pro:Centric
- Pro:Centric V
- Pro:Idiom Digital Right Management (DRM)
- Kensington Lock
- Miracast Technology
- Touchscreen
- No
- Video
- Digital Tuner
- ATSC
- ClearQAM
- Analog Tuner
- NTSC
- SECAM
- PAL
- Video Signal Standard
- HDTV
- Maximum Resolution
- 1366 x 768
- Standard Refresh Rate
- 60 Hz
- Brightness
- 240 Nit
- Scan Format
- 720p
- Aspect Ratio
- 16:9
- High Dynamic Range (HDR)
- Yes
- High Dynamic Range (HDR) Type
- HLG
- Audio
- Speakers
- Yes
- Number of Speakers
- 2
- RMS Output Power
- 10 W
- Sound System
- AI Sound
- Number of Audio Channels
- 2
- Network & Communication
- Wireless LAN
- No
- Bluetooth
- No
- Interfaces/Ports
- HDMI
- Yes
- HDMI Version
- HDMI 2.0
- HDMI 1.4
- Number of HDMI Inputs
- 3
- Total Number of HDMI Ports
- 3
- USB
- Yes
- USB Standard
- USB 2.0
- Digital Audio Output
- Yes
- Headphone
- No
- Network (RJ-45)
- No
- Number of Network (RJ-45) Ports
- 1
- Number of Digital Audio Optical Output
- 1
- Power Description
- Input Voltage
- 100 V AC
- 240 V AC
- Input Voltage Range
- 100 V AC - 240 V AC
- Input Frequency
- 50 Hz
- 60 Hz
- Energy & Performance
- Maximum Operating Power Consumption
- 45 W
- Energy Consumption per Year
- 60 kWh
- Physical Characteristics
- Color Family
- Black
- Product Color
- Ceramic Black
- VESA Mount Compatible
- Yes
- VESA Mount Standard
- 200 x 200
- Mount Type
- Tabletop
- Height
- 17.36" (441 mm)
- Width
- 29.09" (739 mm)
- Depth
- 3.31" (84 mm)
- Height with Stand
- 19.49"
- Width with Stand
- 29.09"
- Depth with Stand
- 9.49"
- Weight (Approximate)
- 10.69 lb (4.85 kg)
- Weight with Stand (Approximate)
- 13.34 lb
- Shipping Height
- 20.87"
- Shipping Width
- 35.63"
- Shipping Depth
- 6.38"
- Shipping Weight (Approximate)
- 16.20 lb
- Miscellaneous
- Additional Information
- AI Acoustic Tuning: No
- Clear Voice: No
- LG Sound Sync: No
- One Touch Sound Tuning: No
- Sound Mode: No
- Global IPTV Support (IPStreaming) :No
- MPEG-2 / MPEG-4 H.264 Decoding :No
- Audio Out (3.5 mm) :Yes (x1)
- AV In (3.5 mm) :Yes (x1)
- DC In :No
- Debug (3.5 mm) :No
- ECI (RJ12) :No
- IR Out :Yes (x1)
- MPI (RJ12) :Yes (x1)
- Pillow Speaker Interface (6 Pin) :No
- Port Location :Rear, Side
- RF / AC In (Power Over Coax) :No
- RF In (Antenna / Cable) :Yes (x1)
- RS-232C (3.5 mm) :Yes (x1)
- RS-232C (D-sub 9-pin) :No
- Service Only (3.5 mm) :Yes (x1)
- ecommerceUse :Yes
- Power Consumption (Typ.) :38 W
- Beacon :No
- Embedded b-LAN :Yes
- Energy Saving Mode :Yes
- External Control Interface :Yes (MPI, RS232C)
- IoT :No
- IR Signal from Receiver (Logic High Pulses) :RS-232C
- IR Signal from Receiver (Logic Low Pulses) :MPI
- LG TV Plus App :No
- Mobile Connection Overlay :No
- Multi-code IR :Yes
- NTP Sync Timer :Yes
- SI Compatible (TVLink Interactive) :No
- Update Time :No
- VLAN ID :No
- V-Lan Tag :No
- Voice Recognition (Standalone / Solution) :No
- XD Engine :No
- EzManager :Yes
- Home (Launcher Bar) :No
- Hotel Mode :No
- HTNG-CEC :1.4
- Insert Image :Yes
- Installer Menu :Yes
- Lock Mode :No
- Motion Eye Care :No
- One Channel Map :LCM
- Pillow Speaker Compatibility :N/A
- Port Block :Yes
- Public Display Mode :No
- USB Auto Playback :No
- USB Auto Playback+ :No
- Welcome Video :No
- HCAP (GEM / FLASH / HTML) :No
- LG Server Compatibility :Not Available
- Mutlicast Ready :No
- Pro:Centric Server :Not Available
- Pro:Centric Data Streaming (IP) :No
- Pro:Centric Data Streaming (RF) :No
- Pro:Centric IP Return Path :No
- Quick Menu Version :N/A
- Service Carousel (TLX, Firmware) :No
- Unicast Ready :No
- hqEnabledFlag :Yes
- Bezel Width (Off Bezel) :L/R/U: 18.8 mm, B: 21.6 mm
- Bezel Width (On Bezel) :L/R/U: 20.7 mm, B: 23.4 mm
- Color :Not Available
- Credenza / Security Aperture :Yes
- Lock Down Plate :Yes
- Stand Type :1 pole - Swivel
- AI Picture Pro :No
- Brightness (Min.) :Not Available
- Contrast Ratio :Not Available
- Dynamic Contrast Ratio :Not Available
- Dynamic Vivid :No
- Game Optimizer :Yes
- Lifetime :Not Available
- Nano Cell Technology :No
- Panel Technology :LCD
- Response Time (G to G) :Not Available
- Viewing Angle (H x V) :Not Available
- CEC (Regulatory) :No
- Conformal Coating :No
- ETL :No
- FCC (Regulatory) :Yes
- ISO 22196 (Antimicrobial) :No
- NOM :No
- NRCan :No
- RoHS (Environmental) :No
- UL Certification :Yes
- Smart Auto Off / Sleep Timer :No
- DIAL :No
- Gallery Mode :No
- Home Office :N/A
- Magic Remote Compatibility :No
- Moving Picture Playback (SDD/Plus HD) :No
- Multi View :N/A
- Pre-loaded Apps :No
- Quick Access :No
- SDP Server Compatibility :No
- Share :No
- Soft AP :No
- SW Clock (World Clock / Alarm) :No
- Web Browser :No
- SNMP :No
- Video Tag :Yes (x2)
- Wake on RF :Yes
- Wake-on-LAN (WOL) :No
- webRTC (Real Time Communication) :No
- System:Main Processor (SoC) :No
- Basic Accessories (included) :Detached 1.8 m Power Cable, AV In Adaptor Cable (3.5 mm TRRS Plug to 3 RCA Jacks)
- Certifications & Standards
- UL
- Energy Star
- No
