- General Information
- Manufacturer
- Netgear, Inc
- Manufacturer Website Address
- http://www.netgear.com
- Brand Name
- Netgear
- Product Series
- MS300
- Product Type
- Ethernet Switch
Expanding Wired Connectivity for SOHO Networks
NETGEAR is expanding its portfolio of next-generation 2.5G Multi-Gigabit Ethernet Plus Switches with the introduction of the new MS305E and MS308E. These switches come with 5 or 8 2.5G Multi-Gig ports in a durable metal case and are designed to seamlessly integrate into any business environment.
Featuring fundamental network capabilities such as network monitoring, traffic prioritization, VLANs, QoS, IGMP Snooping, and an intuitive web-based GUI, these switches provide an adaptable network solution with effortless management. Plus Switches are the perfect upgrade from plug-and-play Unmanaged Switches, delivering essential networking features at an affordable price.
Highlights
- Enable network configuration and management at the price point of Unmanaged Switches
- Simple, yet useful network set-up on top of plug-and-play connectivity
- Business-friendly and easy-to-use web browser-based management GUI
- VLAN support for traffic segmentation
- Quality of Service (QoS) for traffic prioritization
- Auto "denial-of-service (DoS) prevention
- Troubleshoot connection issues via cable test
- Loop detection and broadcast storm controls
- Rate limiting for better bandwidth allocation
- Port mirroring for network monitoring
- Jumbo frame support
- Fanless, silent operation with desktop and wall-mount options
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- Features
- Fanless
- Plug and Play
- Interfaces/Ports
- Total Number of Network Ports
- 5
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 5 x Gigabit Ethernet Network
- Media & Performance
- Media Type Supported
- Twisted Pair
- Ethernet Technology
- 2.5 Gigabit Ethernet
- Network Technology
- 2.5GBase-T
- Network & Communication
- Layer Supported
- 3
- Networking Standards
- IEEE 802.3az
- IEEE 802.3ad
- IEEE 802.3ab
- IEEE 802.3u
- IEEE 802.1p
- IEEE 802.1Q
- IEEE 802.3x
- IEEE 802.3bz
- Management & Protocols
- Manageable
- No
- Reliability
- MTBF
- 4273003 Hour
- Power Description
- Power Source
- Power Adapter
- Power Consumption
- 5.60 W
- Physical Characteristics
- Product Material
- Metal
- Form Factor
- Desktop
- Enclosure
- Wall Mountable
- Height
- 1.1"
- Width
- 6.2"
- Depth
- 4"
- Weight (Approximate)
- 15.87 oz
- Miscellaneous
- Package Contents
- MS305E Ethernet Switch
- Power Adapter
- Rubber Feet
- Installation Guide
- Application/Usage
- Network
- Business
- Certifications & Standards
- CE Class A (EN55032+EN55035)
- UKCA Class A
- FCC Part 15 Class A
- ISED Class A
- VCCI Class A
- RCM
- KC
- BSMI
