- General Information
- Manufacturer
- QNAP Systems
- Manufacturer Website Address
- http://www.qnap.com
- Brand Name
- QNAP
- Product Line
- VioStor
- Product Type
- Video Surveillance Station
Powered by the Intel ® dual-core processor and 4GB of memory, it delivers high performance at a throughput rate of 330 Mbps to ensure stable recordings and smooth playbacks of multiple megapixel cameras. The 6-bay VS-6112 Pro+ is designed for the SMB segment with the features of robust performance, solid reliability and high-definition local display.
The VS-6112 Pro+ can support up to 24TB of storage capacity, with 4TB on each hard drive respectively, to accommodate high quality H.264, MPEG-4, M-JPEG, and MxPEG recording videos. The server-grade mainboard, Sanyo Denki system fan, and heat pipe with fanless design assure the solid reliability for maximized system uptime. Moreover, the VS-6112 Pro+ supports local display via an HDMI cable, with up to 180 fps Full HD 1080p local display by hardware decoding.
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Total Number of Channels
- 12
- Connectivity Technology
- Wired
- System Components
- Network Video Recorder
- Video
- Video Formats
- MxPEG
- Motion JPEG
- MPEG-4
- H.264
- Network & Communication
- Ethernet
- Yes
- Ethernet Technology
- Gigabit Ethernet
- Interfaces/Ports
- USB
- Yes
- USB Standard
- USB 3.0
- Network (RJ-45)
- Yes
- Total Number of Audio In Ports
- 1
- Total Number of Audio Out Ports
- 1
- HDMI
- Yes
- Power Description
- Input Voltage
- 220 V AC
- 240 V AC
- Physical Characteristics
- Height
- 7.3"
- Width
- 10.2"
- Depth
- 9.3"
- Weight (Approximate)
- 12.57 lb
- Miscellaneous
- Package Contents
- 12-Channel / 6-Bay / HDMI Local Display / Tower NVR
- Quick Installation Guide
- CD-ROM (User Manual & Utility Inclusive)
- 28 x Flat Head Screw (for HDD)
- 2 x Ethernet Cable
- Power Cord
- Hard Disk Lock
- Additional Information
- Processor: Dual-core Intel processor
- Memory: 4GB RAM
- HDD Capacity: 6 x 3.5-inch SATA 6Gb/s, SATA 3Gb/s hard drive
- HDD Tray: 6 x hot-swappable and lockable tray
- LED Indicators: Status, LAN, USB, HDD1-6
- Buttons: Power button, One-touch-auto-video-backup button, Reset button
- LCD Panel: Mono-LCD display with backlight
- Alarm Buzzer: System warning
- Form Factor: Tower
- Secure Design: K-Lock security slot for theft prevention
- Fan: 2 x quiet cooling fan (92 mm, 12V DC)
