- General Information
- Manufacturer
- Ubiquiti Inc.
- Manufacturer Website Address
- http://www.ui.com
- Brand Name
- Ubiquiti
- Product Line
- airFiber 11
- Product Type
- Wireless Access Point
airFiber 11 is the first modular airFiber radio system purpose-built for the 11 GHz licensed frequency market that breaks free from the congested 5 GHz band. Housed in a compact, highly efficient form factor, airFiber 11 delivers amazing wireless gigabit+ performance, low latency, and long range, making it ideal for carrier backhaul, building-to-building enterprise use, or public safety applications.
Features
- Full duplex point-to-point radio
- 11 GHz frequency operation
- Up to 1.2+ Gbps throughput
- Includes one high-band duplexer for SISO mode (MIMO mode requires an optional second duplexer)
- Integrates with AF-11G35 11 GHz antenna
- Supports separate TX/RX frequencies
- Accepts PoE or DC power
- Warranty
- Limited Warranty
- 1 Year
- Technical Information
- Frequency Band
- 5 GHz
- Wireless Transmission Speed
- 1.20 Gbit/s
- MIMO Technology
- Yes
- Interfaces/Ports
- Ethernet Technology
- Gigabit Ethernet
- Number of Network (RJ-45) Ports
- 1
- PoE PD Port
- Yes
- Management Port
- Yes
- Physical Characteristics
- Height
- 12.9"
- Width
- 4.4"
- Depth
- 3.4"
- Weight (Approximate)
- 4.98 lb
- Miscellaneous
- Package Contents
- airFiber 11 AF-11 Satellite Radio
- 50V, 1.2A PoE Gigabit Adapter
- 1 x High-band Duplexer
- Additional Information
- Networking Interface:
- Data: 1 x 10/100/1000 Ethernet Port
- Management: 1 x 10/100 Ethernet Port
- Mounting: AF-11G35 Mount Compatible
- Supported Voltage Range: 38-56VDC
- Power Supply: UniFi PoE Switch
- Operating Temperature: -40 to 55° C (-40 to 131° F)
- RF Connectors: 4 x SMA Weatherproof, Two per Chain: TX 0, RX 0 (Chain 0) and TX 1, RX 1 (Chain 1) (2) N-Type Waterproof, One per Duplexer
SYSTEM
- Processor: INVICTUS™ 2 IC
- Maximum Throughput: 1.2+ Gbps
- Encryption: 128-bit AES
- OS: airOS F
- Wireless Modes: SISO/MIMO
- Operating Frequency: 10.7-11.7 GHz (Depends on Regulatory Region)
- Max. Conducted TX Power: 30 dBm (Depends on Regulatory Region)
- Frequency Accuracy: ± 1 ppm
- Channel Bandwidth:
- 3.5/5/7/10/14/20/28/30/40/50/56 MHz
- Selectable
- Programmable Uplink and Downlink Duty Cycles
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
