EIZO CuratOR EX4342 43" Class 4K UHD LED Monitor - 16:9 - White

  • Part: 1263356


Out of Stock

4K UHD Resolution and High Brightness

The monitor uses an energy-efficient LED backlight with a high brightness of 700 cd/m². The high resolution of 3840 x 2160 is four times the size of full HD and faithfully reproduces 4K endoscope and operating microscope images in Ultra High Definition.

Lightweight and VESA Mounting

In the OR, largescreen monitors are typically installed on a wall or attached to ceiling fixtures due to their size and weight. The EX4342's weight of just 16.4 kg and compliance with the VESA standard allow it to be reliably attached to supporting medical carts, providing a wide range of flexible installation options to suit the target environment.

Wide Color Gamut for Distinguishing Tones

During procedures, the operating surgeon needs to be able to differentiate between varying color tones. The EX4342 supports the BT.2020 4K video color standard to ensure that subtle differences between shades of reds and yellows captured by BT.2020-supported cameras are distinguishable on the screen.

HDR Compatibility

HDR (High Dynamic Range) is a range that approximates the human perception of color and light as content is shown on a display device. The monitor is equipped with the perceptual quantization (PQ) curve and hybrid log-gamma (HLG) for supporting HDR. This ensures images from HDR-supported endoscope cameras are displayed without crushing blacks and more closely resemble the human visual system.

Fully Flat Design

Operating rooms contain various medical devices that are arranged according to the type of surgery. Safe handling and a sterile environment play a major role. EIZO's surgical monitors adopt a flat design that saves valuable space and promotes easy cleaning and disinfection. Furthermore, the front is covered with protective glass with IP45 for protection against foreign material and splashes (the whole monitor has an IP32 rating).

Cable Cover for Safety and Hygiene

With the attached cable cover, cable connections can be stored neatly out of sight for maintaining a high level of safety and hygiene in the operating room.

Streamlined Connectivity

With BNC (12G-SDI), and DisplayPort or HDMI, up to 4K UHD images are displayed at 60 frames per second with a single cable over various modalities.

When connected via BNC (12G-SDI), stable transmission is achieved even over long distances of 30 meters.

Output Images Directly to Multiple Monitors

The monitor is also equipped with BNC (12G-SDI), DisplayPort, and DVI output terminals so input video can be passed through and output directly to the next monitor. The same image is displayed on multiple monitors making information sharing among medical staff smooth in the operating room, while alleviating excess cabling.

180° Rotation and Mirroring

Regardless of the orientation of the surgical camera, you can rotate the displayed image by 180° or mirror it to find the perfect operating angle. This is useful for aligning the image with the line of sight of surrounding assistants and surgeons, improving convenience in the operating room.

View Two Signals on One Screen

Two different types of signal sources can be viewed simultaneously on one monitor, either side by side using the PbyP (Picture-by-Picture) or one above the other using the PinP (Picture-in-Picture) function. For example, this allows monitoring vitals or ultrasound endoscopes simultaneously in addition to surgical images.

  • General Information
    • Manufacturer
    • EIZO
    • Manufacturer Website Address
    • http://www.eizo.com
    • Brand Name
    • EIZO
    • Product Line
    • CuratOR
    • Product Type
    • LED Monitor
  • Warranty
    • Limited Warranty
    • 5 Year

  • Technical Information
    • Number of Screens
    • 1
    • Screen Size Class
    • 43"
    • Viewable Screen Size
    • 43"
    • Screen Mode
    • 4K UHD
    • Panel Technology
    • In-plane Switching (IPS) Technology
    • Response Time
    • 8 ms
    • Response Time Details
    • 8ms GTG
    • Aspect Ratio
    • 16:9
    • Pixel Pitch
    • 9.6 mil
    • Horizontal Viewing Angle
    • 178°
    • Vertical Viewing Angle
    • 178°
    • Mount Type
    • Wall Mountable
    • Ceiling Mountable
    • Backlight Technology
    • LED
    • Features
    • Remotely Operated
    • Picture by Picture
    • Picture in Picture
    • On-screen Display (OSD)
    • Wide Color Gamut (sRGB)
    • High Dynamic Range (HDR)
    • Glass Hardness
    • 9H
    • Ingress Protection (IP) Rating
    • IP45
    • IP32
    • Active Display Area (H x V)
    • 37.06" x 20.84"
  • Video
    • Maximum Resolution
    • 3840 x 2160
    • Color Supported
    • 1.07 Billion Colors
    • Native Contrast Ratio
    • 1,000:1
    • Brightness
    • 700 Nit
    • Color Gamut
    • BT.2020
  • Interfaces/Ports
    • HDMI
    • Yes
    • DisplayPort
    • Yes
    • Number of HDMI Inputs
    • 1
    • Total Number of HDMI Ports
    • 1
    • Number of DisplayPorts
    • 2
    • Number of DVI Ports
    • 2
    • DVI-D
    • Yes
  • Power Description
    • Operating Power Consumption
    • 144 W
    • Frequency
    • 50 Hz
    • 60 Hz
    • Maximum Power Consumption
    • 144 W
  • Physical Characteristics
    • VESA Mount Compatible
    • Yes
    • VESA Mount Standard
    • 400 x 200
    • VESA Screw Dimensions
    • M8
    • Color Family
    • White
    • Color
    • White
    • Weight (Approximate)
    • 36.16 lb
  • Miscellaneous
    • Package Contents
      • CuratOR EX4342 Widescreen LED Monitor
      • Cable Cover
      • 2 x Cable Tie
      • 4 x Monitor Attachement Screws
      • Utility Disk (Instructions For Use, Installation Manual)
    • Environmentally Friendly
    • Yes
    • Environmental Compliance
    • China Restriction of Hazardous Substances (China RoHS)
    • Restriction of Hazardous Substances (RoHS)
    • Waste Electrical and Electronic Equipment Directive (WEEE)
