- General Information
- Manufacturer
- LG Electronics
- Manufacturer Website Address
- https://solutions.lg.com/us
- Brand Name
- LG
- Product Series
- ML5K
- Product Type
- LCD TV
High Haze UHD Hospital & LTC TV | High-Performance with webOS™
LG webOS™ platform enhances user convenience with intuitive GUI and simple app development tools.
Conformal Coating
In various places the ML5K series is unable to avoid exposure to environments containing dust, humidity, etc. which may hamper performance over time. The conformal coating on power board reduces these risks by protecting ML5K series from salt, dust, iron powder, humidity, etc.
Mobile Content Management
You can easily create your own content using LG's Promota* application, which is downloadable on a mobile device. With Promota, you can add text and images to create an online profile for your business and deliver information such as event news, seasonal menus, promotions, and even more to your customers while recommending easy-to-use templates relevant to your industry.
Compatible with AV Control System
The ML5K series has been certified Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.
- Warranty
- Limited Warranty
- 4 Year
- Technical Information
- Screen Size Class
- 43"
- Viewable Screen Size
- 43"
- Backlight Technology
- Edge LED
- Response Time
- 8 ms
- Operating System
- webOS 6.0
- Features
- In-plane Switching (IPS) Technology
- Wake on LAN (WOL)
- Crestron Inside
- FailOver
- Picture in Picture
- Tile Mode Setting (15 × 15)
- Wake on LAN (WOL)
- Orientation
- Landscape/Portrait
- Operation Hours
- 24 Hours/7 Days
- Video
- Maximum Resolution
- 3840 x 2160
- Standard Refresh Rate
- 60 Hz
- Dynamic Contrast Ratio
- 1,000,000:1
- Native Contrast Ratio
- 1,200:1
- Brightness
- 500 Nit
- Scan Format
- 2160p
- Color Depth
- 8-bit+FRC
- Color Gamut
- 95% BT.709
- Aspect Ratio
- 16:9
- Viewing Angle
- 178° Horizontal/178° Vertical
- Audio
- Speakers
- Yes
- Number of Speakers
- 2
- RMS Output Power
- 10 W
- Network & Communication
- Ethernet
- Yes
- Wireless LAN
- Yes
- Memory
- Flash Memory Capacity
- 16 GB
- Interfaces/Ports
- HDMI
- Yes
- Number of HDMI Inputs
- 3
- Number of HDMI Outputs
- 1
- USB
- Yes
- USB Standard
- USB 2.0
- DVI
- Yes
- DisplayPort
- No
- Network (RJ-45)
- No
- Number of Network (RJ-45) Ports
- 1
- Power Description
- Input Voltage
- 120 V AC
- Input Frequency
- 50 Hz
- 60 Hz
- Energy & Performance
- Maximum Operating Power Consumption
- 120 W
- Environmental Conditions
- Operating Temperature Range
- 32°F (0°C) to 104°F (40°C)
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- VESA Mount Compatible
- Yes
- VESA Mount Standard
- 200 x 200
- Mount Type
- Wall Mountable
- Height
- 22.40" (569 mm)
- Width
- 37.90" (963 mm)
- Depth
- 1.60" (41 mm)
- Weight (Approximate)
- 24.69 lb (11.20 kg)
- Miscellaneous
- Package Contents
- 43ML5K-B 43'' ML5K Series UHD Healthcare Digital Signage
- Remote Control including battery (x2)
- Power Cord
- QSG
- Regulation Book
- Phone to RS-232C Adapter
- Application/Usage
- Indoor
- Hospitality
- Airport
- Retail
- Meeting Room
- Shopping Mall
- On Screen Display (OSD) Languages
- English
- Arabic
- Simplified Chinese
- Czech
- Danish
- Dutch
- Finnish
- French
- German
- Greek
- Italian
- Japanese
- Korean
- Norwegian
- Brazilian Portuguese
- Russian
- Spanish
- Swedish
- Turkish
- Additional Information
- hqEnabledFlag: Yes
- Panel:Color Gamut: BT709 95%
- Panel:Color Depth (Number of Colors): 1.07 Billion Colors, 8 bit + FRC
- Electrical:Power Consumption (Power Off): 0.5W
- Electrical:Power Type: Built-in Power
- Mechanical:Shipping Weight: 30 lbs / 13.7 kg
- Mechanical:Dimensions (W x H x D): 37.9 x 22.4 x 1.6 in / 962.5 x 568.0 x 39.9 mm (with LG Logo)
- Mechanical:Shipping Dimensions (W x H x D): 41.7 x 26.0 x 6.0 in / 1060.0 x 660.0 x 152.0 mm
- Mechanical:Weight with Stand: 26.0 lbs / 11.8 kg
- Picture-by-Picture (PBP): Yes (4)
- Picture-in-Picture (PIP): Yes
- Smart Energy Saving: Yes
- USB Plug & Play: Yes
- Assembled In: Mexico
- TAA Compliance: No
- Panel:Surface Treatment (Haze): 05
- Electrical:Power Consumption (Typ.): 80W
- Connectivity:RS-232C In (3.5 mm 4-pin): Yes (x1)
- Auto Brightness Sensor: Yes
- Onscreen Display Languages: Arabic, Chinese (Original), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Italian, Japanese, Korean, Norwegian, Polski, Portuguese (Brazil), Portuguese (Europe), Russian, Simplified Chinese, Spanish, Swedish, Türkçe
- Warranty & Other:Optional Accessories: Wall bracket (LSW240B), OPS Kit (KT-OPSF)
- Regulatory & Certifications:FCC (Regulatory): EMC Class A
- Regulatory & Certifications:Energy Star (Environmental): Yes
- Panel:Operation Hours (Hours per Day / Days per Week): 24/7
- Panel:Lifetime: Up to 50,000 Hrs
- Crestron Certified Compatibility: Yes
- Beacon: Yes
- Play Via URL: Yes
- Failover: Yes
- Electrical:Power Consumption (Smart Energy Saving - 70%): 56W
- Electrical:BTU Heat Generation (Max.): 410 BTU
- Electrical:BTU Heat Generation (Typ.): 273 BTU
- Mechanical:Tilt (Face Down): Yes (Max 15º degree, 30ºC temperature, humidity 50%)
- Mechanical:Bezel Color: Black
- Mechanical:Bezel Width: T/R/L: 8.4 mm, B: 14.4 mm
- Mechanical:Dimensions with Stand (W x H x D): 37.9 x 24 x 11.4 in / 962.5 x 613 x 290.0 mm
- IR In (3.5 mm): Yes
- Connectivity:Audio In (3.5 mm): Yes (x1)
- Audio Out (3.5 mm): Yes (x1)
- Connectivity:RS-232C Out (3.5 mm): Yes (x1)
- Protective Glass:Shatter-Proof: Yes
- Local Key Operation: Yes
- Temperature Sensor: Yes
- Gapless Playback: Yes
- Control Manager: Yes
- SI Server Setting: Yes
- Setting Data Cloning: Yes
- Status Mailing: Yes
- Auto Set ID: Yes
- ISM Method: Yes
- Group Manager: Yes
- Booting Logo Image: Yes
- Network Ready: Yes
- RS-232C Sync: Yes
- webRTC (Real Time Communication): Yes
- Video Tag: Yes (4)
- PM mode: Yes
- Local Network Sync: Yes
- Screen Rotation: Yes
- Tile Mode Setting: Yes (Max. 15 x 15)
- External Input Rotation: Yes
- SNMP: Yes
- Local Contents Scheduling: Yes
- Hospitality Features:Pro:Idiom: Yes
- LG Software Compatible:SuperSign CMS: Yes
- SuperSign Control+: Yes
- LG Software Compatible:SuperSign WB: Yes
- LG Software Compatible:Mobile CMS: Yes
- LG Software Compatible:ConnectedCare: Yes
- Environmental Conditions:Operation Humidity: 10% to 80%
- Panel:Orientation: Portrait / Landscape
- Electrical:Power Consumption (Display Power Management - DPM): 0.5W
- Warranty & Other:Basic Accessories (included): Remote Controller (include battery 2ea), Power Cord, QSG, Regulation Book, 3.5mm to RS232C Adapter
- Certifications & Standards
- NRTL FCC Class "A" UL62368-1
- Energy Star
- Yes
