- General Information
- Manufacturer
- HPI SOURCING - NEW
- Brand Name
- HPI SOURCING - NEW
- Product Line
- Elite Mini
- Product Series
- 800 G5
- Product Type
- Desktop Computer
- Processor
- Processor Manufacturer
- Intel
- Processor Type
- Core i5
- Processor Generation
- 9th Gen
- Processor Model
- i5-9500T
- Processor Core
- Hexa-core (6 Core)
- Processor Speed
- 2.20 GHz
- Maximum Turbo Speed
- 3.70 GHz
- L3 Cache
- 9 MB
- vPro Technology
- Yes
- Processor Threads
- 6
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- Q370
- Memory
- Standard Memory
- 16 GB
- Maximum Memory Supported
- 64 GB
- Memory Technology
- DDR4 SDRAM
- Memory Speed
- 2666 MHz
- Memory Configuration
- 1 x 16GB
- Total Number of Memory Slots
- 2
- Number of Occupied Memory Slots
- 1
- Intel Optane Memory Ready
- Yes
- Storage
- Drive Type
- SSD
- Total Solid State Drive Capacity
- 512 GB
- Solid State Drive Interface
- PCI Express NVMe
- SSD Form Factor
- M.2
- Display & Graphics
- Graphics Controller Manufacturer
- Intel
- Graphics Controller Model
- UHD Graphics 630
- Graphics Memory Technology
- DDR4 SDRAM
- Graphics Memory Accessibility
- Shared
- Network & Communication
- LAN Manufacturer
- Intel
- LAN Model
- I219-LM
- Ethernet Technology
- Gigabit Ethernet
- Wireless LAN
- Yes
- Wireless LAN Standard
- IEEE 802.11ax
- Bluetooth
- Yes
- Interfaces/Ports
- Total Number of USB Ports
- 7
- Number of USB 3.1 Gen 1 Ports (Front)
- 1
- Number of USB 3.1 Gen 1 Ports (Rear)
- 2
- Number of USB 3.1 Gen 2 Ports (Front)
- 1
- Number of USB 3.1 Gen 2 Ports (Rear)
- 2
- USB Type-C (Front)
- Yes
- USB Type-C Detail
- 1 x USB Type-C™ 3.1 Gen 2
- Number Of Ethernet Ports
- 1
- Number of DisplayPort Outputs (Rear)
- 3
- DisplayPort (Rear)
- Yes
- Optional Ports
Details regarding optional ports aggregated from the information available for this product's family/series.
- 1 x USB Type-C™ 3.1 Gen 2
- 1 x Serial (RS-232)
- Operating System
- Operating System Platform
- Windows
- Operating System
- Windows 10 Pro
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Maximum Power Supply Wattage
- 65 W
- Frequency
- 47 Hz
- 63 Hz
- Physical Characteristics
- Form Factor
- Mini PC
- Height
- 1.3"
- Width
- 7"
- Depth
- 6.9"
- Weight (Approximate)
- 2.12 lb
- Miscellaneous
- Package Contents
- EliteDesk 800 G5 Desktop Mini PC
- Power Adapter
- Features
- Tool-less Access
- Security Slot
- Low Halogen
- Energy Star
- Yes
- Energy Efficiency Certification
- China Energy Conservation Program (CECP)
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
